EVA Foam Molding & Compression Services

Closed black compression-molded EVA hard case

Send your size, use, and a photo or sample. We’ll come back with options and a quote.

Email: sales@magneteva.com

Compression molding turns EVA foam into three-dimensional shapes that cannot be cut from a flat sheet: curved case shells, contoured trays, raised logos and shaped footbeds. Foam is pressed into a mold with heat, and comes out in the shape of the mold. We mold EVA parts to your sample, drawing or photo. MAGNETEVA was founded in 2009.

What compression molding is for

Cutting works for flat parts and straight-walled cavities. Molding is the choice when a part needs curves, varying thickness, rounded edges or a logo pressed into the surface. A molded EVA case shell, like the cases on this page, keeps its shape in use.

What we mold

Options

OptionWhat you can choose
ShapeTo your sample, drawing or photo; a new mold is made for your part
LogoMolded into the surface
ColorTo your requirement
HardnessSofter or firmer foam, matched to the part
Density range30 to 150 kg/m³
Hardness rangeShore C 10 to 70
Thickness range1 mm to 100 mm
Maximum sheet size1500 x 3000 mm
Tolerance±0.5 mm
Color matchingPantone matching
Red molded EVA case

Where molded EVA is used

  • Tool cases and organizer inserts
  • Electronics protective packaging
  • Medical equipment cases
  • Yoga and fitness products
  • Shoe insoles and footbeds
  • Sports accessories

Send your size, use, and a photo or sample. We’ll come back with options and a quote.

Email: sales@magneteva.com

How a custom molding order works

  1. Send your inquiry with size, use and a sample, drawing or photo.
  2. We review the part and suggest foam and hardness, and quote the mold and the parts.
  3. We make the mold and a molded sample for you to check shape and fit.
  4. Production follows the approved sample.
  5. Parts are packed as agreed, then shipped.

We customize to customer requirements from a sample, drawing or photo. Tell us your quantity and we’ll suggest the right option.

FAQ

When do I need molding instead of cutting?

When the part has curves, rounded edges, varying thickness or a raised logo. For flat parts with straight-walled cavities, die cutting is usually simpler. Send the design and we’ll tell you which fits.

Do I need a new mold?

A new part usually needs its own mold. Send the sample or drawing and we’ll explain what the mold involves for your design.

Can you mold my logo into the part?

Yes. A logo or pattern can be formed in the mold so it appears on every part.

What do you need from me to quote?

A sample, drawing or photo, the main sizes, the use and the color. Send us your details and we’ll get back to you with options.

How many parts do I need to order?

Tell us your quantity and we’ll suggest the right option.
